Part Number - AS-UNT1126-0

AS-UNT1126-0 is

In Stock Ships Today!In Stock Ships Today!In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 |

Rate the AS-UNT1126-0
4.5/5 on 2 reviews

Product Details

  • Metasys AS Unitary Controller 1126-0 (ASUNT11260)
  • Manufacturer: Johnson Controls
  • Series: Metasys AS

Product Description

The Johnson Controls AS-UNT1126-0 (ASUNT11260) is a Metasys AS Unitary Controller. The voltage cache is between 20 and 30VAC, operating at a frequency of 50/60Hz. Then, also, the power consumption is no more than 7VA. The paragraph below will delineate the various inputs and outputs of the AS-UNT1126-0 unitary controller.

Here are the various inputs and outputs of the AS-UNT1126-0 unitary controller. There are six analog inputs, six binary inputs, two analog outputs, and six binary outputs. The analog input has 1K ohms and can perform at either 0 to 10VDC or at 0 to 2VDC and a current of 1.4mA. The binary output has a voltage range of 0 to 30 for both VAC and VDC; the current may be either 4.8mA AC or 3.0mA DC. The AS-UNT1126-0 unitary controller’s analog output functions with a voltage of 0 to 10VDC while it is running at 10mA; however, also concerning the analog output, its greatest current is 20mA and with the external current, only up to 37mA is available. Lastly, the binary output has a voltage of 24VAC but may become 30VAC, and it may also range from 5 to 28VDC.

For mounting the AS-UNT1126-0 unitary controller, either a DIN rail or screws utilized for mounting. If the DIN rail is utilized, the DIN rail must be used, and the unitary controller is able to be easily secured to the rail by tacking it onto the rail. Also, for mounting with screws, it is important to mount properly so that any necessary connection may be made.

Here is the source material that may have been referenced:

Technical Specifications

Part Number: AS-UNT1126-0 (ASUNT11260)
Module Type: Unitary Controller
Voltage/Frequency: 20 to 30VAC, 50/60Hz
Weight: 1lb (approx.)

Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Johnson Controls Metasys AS Shipping options vary by location. Call for an accurate quote.


  • The Johnson Controls AS-UNT1126-0 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.

Additional Information

TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.

Authorized Distributors

A Johnson Controls Authorized Distributor for METASYSAS is not the only source for Johnson Controls products. Many of the Johnson Controls products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Johnson Controls METASYSAS parts available for purchase.

More Information: Repair AS-UNT-1126-0 ASUNT11260
