AS-UNT141-1


Part Number - AS-UNT141-1

AS-UNT141-1 is

In Stock Ships Today!In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the AS-UNT141-1
5.0/5 on 2 reviews



Product Details

  • Metasys AS Unitary Controller 141-1 (ASUNT1411)
  • Manufacturer: Johnson Controls
  • Series: Metasys AS

Product Description

The Johnson Controls AS-UNT141-1 (ASUNT1411) is a Metasys AS series unitary controller. The voltage of the unitary controller is 24VAC with the standard frequency of 50/60Hz. The power consumption of this unitary controller is 40VA. The AS-UNT141-1 unitary controller has many inputs and outputs; all these will be adumbrated in the next paragraph.

There are six analog inputs and four binary inputs that are imputed to the AS-UNT1[][]-1 type. However, the AS-UNT141-1 controller has two analog outputs and six binary outputs. The analog input has 0 to 2K ohms and a voltage which ranges from 0-10VDC, but it may be selected to function at voltages of 0-5VDC or 1-5VDC. The binary input of the AS-UNT141-1 unitary controller is a stable 24VAC. The analog output is given a voltage range if 0-10VDC while running on a current of 10ma. Finally, the binary output of the AS-UNT141-1 controller is 24VAC while operating at 0.5A or 0.8A.

By using the N2 Bus network, the AS-UNT141-1 controller may be placed in a certain position within a configuration. One means is to connect the unitary controller to a Johnson Controls DX-9100 and AHU control modules or it may link with a sector terminal, metastat, and ILC. The AS-UNT141-1 controller may also be in an N2 Bus system may link with a PC or panel, a DX-6100 and AHU control module, and the EWC10. There is also a zone Bus. Both Buses are in the screw terminal block which may be detached.

Here is the source material that may have been referenced:
http://www.vikingcontrols.com/_documents/Product/635065.PDF


Technical Specifications

Part Number: AS-UNT141-1 (ASUNT1411)
Module Type: AS Unitary Controller
Voltage/Frequency: 24VAC, 50/60Hz
Weight: 1.4lbs (0.64kg)


Related Parts

DX-9100-8900 - Johnson Controls WALL MOUNTING BASE
DT-9100-8004 - Johnson Controls OPERATOR INTERFACE METASYS LCD DISPLAY
DX-9100-8996 - Johnson Controls CABINET DOOR MOUNTING



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Johnson Controls Metasys AS Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Johnson Controls AS-UNT141-1 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
