MS-FEC2611-0


Part Number - MS-FEC2611-0

MS-FEC2611-0 is

In Stock Ships Today!In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MS-FEC2611-0
4.7/5 on 3 reviews



Product Details

  • Metasys MS Input Output Equipment Controller (MSFEC26110)
  • Manufacturer: Johnson Controls
  • Series: Metasys MS

Product Description

The Johnson Controls MS-FEC2611-0 (MSFEC26110) is a Metasys MS series input output equipment controller with 17 points. The equipment controller points are divided as 6 universal inputs (UI), 2 binary inputs (BI), 3 binary outputs (BO), 4 configurable outputs (CO), and 2 analog outputs (AO). The MS-FEC2611-0 can be mounted on the 35mm DIN rail or on a screw mount on a level surface with three clips that are incorporated on the controller. This product communicates by the BACnet. This allows for master-slave communication. The Johnson Controls METASYS MS-FEC2611-0 can be melded with other METASYS input output modules (IOM). This product communicates by the BACnet. The MS-FEC2611-0 is able to connect wirelessly by a ZFR1800 series bus system. This permits wireless communication with others FECs.

The dimensions of the MS-FEC2611-0 input output equipment controller is 150mm by 190mm by 53mm (5.91in by 7.48in by 2.07in) with the terminals and mounting clips included. The enclosure rating of this input output controller is IP20. The IP20 protects the MS-FEC2611-0 equipment controller from accidental finger contact or contact by some other foreign object.

The MS-FEC2611-0 input output equipment controller has a voltage of 24VAC and a frequency of 50/60Hz. Its current-voltage power consumption is 14VA; the VA rating does not include power given by extraneous devices which are connected to the BO or CO. Its memory is 1MB flash memory and it has a Random Access Memory (RAM) of 512KB. This permits one to download normal or customize applications by making use of the Controller Configuration Tool (CCT) software.

Here are the source material that may have been referenced:
https://cgproducts.johnsoncontrols.com/cat_pdf/1900346.pdf
https://www.emccontrols.net/media/documents/fec.pdf
https://www.enclosurecompany.com/ip-ratings-explained.php


Technical Specifications

Part Number: MS-FEC2611-0 (MSFEC26110)
Module Type: Equipment Controller
Number of Input Output Points: 17 Voltage/Frequency: 24VAC, 50/60Hz
Weight: 1.1lbs (0.5kg)


Related Parts

DX-9100-8996 - Johnson Controls CABINET DOOR MOUNTING
DX-9100-8900 - Johnson Controls WALL MOUNTING BASE
DT-9100-8004 - Johnson Controls OPERATOR INTERFACE METASYS LCD DISPLAY



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Johnson Controls Metasys MS Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Johnson Controls MS-FEC2611-0 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
