Part Number - A0J2HCPU



Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the A0J2HCPU
4.0/5 on 1 review

Product Details

  • A Series CPU Input Output Control Module (A0J2H-CPU)
  • Manufacturer: Mitsubishi
  • Series: A Series CPUs

Product Description

The Mitsubishi A0J2HCPU (A0J2H-CPU) is an CPU input output control module from the A series. The control module can have up to 336 input output points unless an extension base is utilized, and then there can be 480 points. The memory capacity is from the RAM, and it is 32k bytes. An EMPROM may be able to be connected to the control module. The current that is consumed by the A0J2HCPU control module is 0.4 Amp when the voltage is 5VDC. Then the quantity of instructions possessed by the CPU control module varies on the type of instruction utilized. These are the types of instructions: the sequence, basic, and application. There are 22 sequence types, 131 basic types, and 109 application types.

The A0J2HCPU control module can connect to the extension base in this way. A cable attaches to three control modules that are in the system, this then links to the extension base. On the extension base may be placed a control module that is of the input output group and a module that perform distinctive functions.

There are multiple exterior attributes on the A0J2HCPU input output control module. There is a terminal block that is employed to attach with a power supply. The voltage may be chosen to be either the 100 or 200VAC. Also, upon the A0J2HCPU module there is a RS-422 port. There is a switch that can either select the ‘RUN/STOP, a ‘RESET, or the “LATCH CLEAR’ mode. There is a light that when it is on indicates that the power is being properly supplied.

Here is the manual referenced:

Technical Specifications

Part Number: A0J2HCPU (A0J2H-CPU)
Module Type: Control Module
Number of Input Output Points: 336
Memory Capacity: 32k bytes
Weight: 1.65lbs (0.75kg)

Related Parts

F943GOT-LWD - Mitsubishi Operator Interface
MR-J4-100B - Mitsubishi Melservo MR-J4 Servo Amplifier
A4UCPU - Mitsubishi INPUT OUTPUT Controller

Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi A Series CPUs Shipping options vary by location. Call for an accurate quote.


  • The Mitsubishi A0J2HCPU comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
