MR-J2-100A


Part Number - MR-J2-100A

This MR-J2-100A is

In Stock Ships Today!


\"bulletNew In Stock

Call 1-800-479-8084

Rate the MR-J2-100A
5.0/5 on 3 reviews





Product Details

  • Melservo MR-J2 Servo Amplifier (MRJ2100A)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J2

Product Description

The Mitsubishi MR-J2-100A (MRJ2100A) is a 1kW, 200V Melservo MR-J2 servo amplifier. The power supply of this servo amplifier has a voltage which ranges from 200 to 230VAC and operates on a 3-phase voltage. The frequency of this power supply is 50/60Hz. The voltage, nevertheless, may magnifies its range between 170 to 253VAC with an identical operations of 3-phase. Also, the frequency of the MR-J2-100A servo amplifier may shift between +5% and -5% of 50/60Hz. The frequency response of this servo amplifier has a speed of 250Hz.

The environment of the MR-J2-100A servo amplifier must reside in an area or precinct that is not exposed to alkaline or caustic gases or other impinging substances like dust.

The MR-J2-100A servo amplifier may only be concatenated one servo motor, the HC-SF102. The servo motor that may be utilized, the HC-SFS102, is a medium inertia and capacity motor.

The MR-J2-100A servo amplifier has four port and six screws which are on the terminal block of the servo amplifier. The CN1B port can link with a terminal block. The CN2 connector can connect to the encoder of the HC-SFS102. And the CN3 port may connect to a personal computer in order to create a RS-232C communications. On the terminal block on the control circuit are six screw terminals: L1, L2, L3, U, V, and W. The U, V, and W terminals on the MR-J2-100A servo amplifier link to the servo motor utilizing a servo motor power cable. The L1, L2, and L3 attach to the magnetic contactor which then must link to the power cable.

Here is the manual referenced:
https://dl.mitsubishielectric.com/dl/fa/document/manual/servo/sh030006/sh030006j.pdf


Technical Specifications

Manufacturer: Mitsubishi
Part Number: MR-J2-100A (MRJ2100A)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC, 3-phase 50/60Hz
Output Wattage: 1kW
Weight: 3.7lbs (1.7kg)


Related Parts

MR-J2-100B - Mitsubishi Melservo MR-J2 Servo Amplifier, 1KW, 200V (MRJ2100B)
HC-SF81 - Mitsubishi Melservo HC Servo Motor, 850W (HCSF81)
HC-SF102 - Mitsubishi Melservo HC Servo Motor, AC, 2KW (HCSF102)
HC-SF102B - Mitsubishi Melservo HC Servo Motor with Brake, AC, 2KW (HCSF102B)
HC-SF102BK - Mitsubishi Melservo HC Servo Motor with Brake Key, AC, 2KW (HCSF102BK)
HC-SF103B - Mitsubishi Melservo HC Servo Motor with Brake, 1KW (HCSF103B)
HC-SF103K - Mitsubishi Melservo HC Servo Motor with Key, 1KW (HCSF103K)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J2-100A comes with a one-year warranty.
