MR-J2S-100B


Part Number - MR-J2S-100B

MR-J2S-100B is


Available


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the MR-J2S-100B
5.0/5 on 1 review


Product Details

  • Melservo MR-J2 Servo Amplifier 1kW (MRJ2S100B)
  • Manufacturer: Mitsubishi
  • Series: MELSERVO MR-J2

Product Description

The Mitsubishi MR-J2S-100B (MRJ2S100B) is a Melservo MR-J2 series servo amplifier with an output wattage of 1kW. The servo amplifier has an input of 200-230 Volts with a frequency of 50-60Hz and outputs 170 Volts with the frequency 0-360Hz and generates a total of 1kW. The MR-J2S-100B servo amplifier 1kW also has a RS-232C/RS-422 cable that allows for personal computer interface. A participant in the J2S-B amplifier group, the MR-J2S-100B can abet in connecting itself to controllers by the Servo System Control Network (SSCNET), which also permits the amplifier to control motor break.

There is a battery chamber in the MR-J2S-100B servo amplifier where an optional MR-BAT Battery can be placed. Many motors can be matched with the MR-J2S-100B, but it is known to function well with a specific motors from the HC-SF motor series, that is the HC-SFS-102 motor. A CN2 connector can attach motors to this amplifier. The MR-J2S-100B becomes compatible with the SSC Network when it is hitched with a CN1A connector for managing motion controller (Q172, Q173, A171SH, A172SH, A173UH) or positioning controllers (QD75M, A1SD75M); the use of a CN1B connector can also connect with the SSC Network. With the same connector just mentioned, the MR-J2S-100B can be able to append with kindred servo amplifiers. Lastly, the CN3 connector is capable of linking to a personal computer. The personal computer may also have a MR Configurator software disc.

Ambient temperature in the environs of the MR-J2S-100B servo amplifier 1kW should be between 0 and 55 degrees Celsius (32 to 131 degrees Fahrenheit) in order for it to maintain its normal operations.

Here are the manuals that may have been referenced:
http://dl.mitsubishielectric.com/dl/fa/document/catalog/servo/l03007/l03007d.pdf
http://www.andreoniautomazione.it/mr-j2-super-catalogue_gb.pdf


Technical Specifications

Part Number: MR-J2S-100B (MRJ2S100B)
Module Type: Servo Amplifier
Voltage/Frequency: 200-230VAC 50/60Hz, 3 Phase
Output Wattage: 170V. 1kW
Weight: 3.7lbs (1.7kg)


Related Parts

HC-SFS81 - Mitsubishi Melservo HC Servo Motor
HC-SFS81B - Mitsubishi Melservo HC Motor with Brake
MR-J2S-100B4 - Mitsubishi Servo Amplifier



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi MELSERVO MR-J2 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Mitsubishi MR-J2S-100B comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
