Part Number - Q02HCPU

Q02HCPU is

In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the Q02HCPU
3.6/5 on 5 reviews

Product Details

  • System Q CPUs Input Output Control Module (Q02H-CPU)
  • Manufacturer: Mitsubishi
  • Series: System Q CPUs

Product Description

The Mitsubishi Q02HCPU (Q02H-CPU) is a System Q CPU high-speed input output control module with 4,096 points. This control module has program capacity of 28K steps. The amount of input output (I/O) points for the device is 8,192, but generally the standard total points of this control module are 4,094. There are many various registers, relays, and outputs that produce or receive many points as is outlined in this products manual. The Q02HCPU control module has the speeds of processing each instruction is roughly 34ns for an instruction command named ‘LD’ and 102ns for instructions command called ‘MOV’. There is another speed of 782ns for processing another type of instruction.

The Q02HCPU high-speed input output control module may connect with up to seven base extensions along with the main base in which it would be situated. Upon all these bases there may be placed up to 64 modules. With all these connections created, the greatest distance between the main base and the farthest extension may be 13.2 meter.

In a conceivable configuration the Q02HCPU System Q control module may attach to multiple input output modules. With these connections within the configuration accomplished; this configuration, in which the control module is in, can connect to servo amplifiers which are attached to a servo motor. This connection is made possible by the Servo System Control Network (SSCNET). The Q02HCPU control module may also link with a host computer in this configuration, by utilizing the Ethernet system. Besides these two mentioned networks, the Q02HCPU control module can attach to a CC-link and remote input output system through the connection between other configurations.

Technical Specifications

Part Number: Q02HCPU (Q02H-CPU)
Module Type: Input Output Control Module
Servo System Control Network (SSCNET)
Number of Input Output Points: 4,096
Program Capacity: 28k steps
Weight: 0.3 (approx.)

Related Parts

HC-KFS43BK - Mitsubishi Servo Motor with Brake Key (HCKFS43BK)
Q02CPUATD - Mitsubishi System Q CPU Control Module
HC-MFS43BK - Mitsubishi Servo Motor with Brake Key

Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Mitsubishi System Q CPUs Shipping options vary by location. Call for an accurate quote.


  • The Mitsubishi Q02HCPU comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.
