- Melservo MR-J2 Servo Amplifier SSC NETWORK 2000W 200V (MRJ2200B)
- Manufacturer: Mitsubishi
- Series: MELSERVO MR-J2
Product DescriptionThe Mitsubishi MR-J2-200B (MRJ2200B) is a 2kW, 200V Melservo MR-J2 servo amplifier SSC NETWORK. The voltage of the power supply has 3-phases and the voltage itself compasses from 200 to 230VAC while the frequency is 50/60Hz. The voltage may nevertheless exceed the standard range and it is sanctioned to fluctuate between 170 to 253VAC. The frequency may waver between +5% to -5% of the original 50/60Hz. The frequency response has a speed of 250Hz.
The MR-J2-200B servo amplifier may connect to a variety of servo motors, specifically those of the HC-SF, HC-RF, or HC-UF series. The servo motors which may be applied to this servo amplifier are those noted below: HC-SF121, HC-SF201, HC-SF152, HC-SF202, HC-SF153, HC-SF203, HC-RF153, and HC-UF152.
The MR-J2-200B servo amplifier has twelve screw terminals and four ports. There are two ports which can connect to fellow servo amplifiers. The CN1A port may link to a precursory servo amplifier by the CN1B port; using the CN1B port the MR-J2-200B servo amplifier may connect to a succeeding servo amplifier’s CN1A port. Then the CN3 port can attach to a personal computer that utilizes a certain system software. The last port, the C2 port, links to the encoder of the servo motor employed. The servo motor used by the MR-J2-200B servo amplifier may also link with three of its screw terminals, U, V, and W, terminals. Many of the other screw terminals can attach to a reactor which can link with a magnetic contactor by the L1, L2, and L3 terminals.
Here is the manual that may have been referenced:
Technical SpecificationsPart Number: MR-J2-200B (MRJ2200B)
Module Type: Servo Amplifier
Voltage/Frequency: 200 to 230VAC 3-phase, 50/60Hz
Output Wattage: 2kW
Weight: 4.4lbs (2.0kg)
Related PartsMR-J2-200A - Mitsubishi Melservo MR-J2 Servo Amplifier, 3 PHASE (MRJ2200A)
HC-SF201K - Mitsubishi Melservo HC Servo Motor with Key, 2KW (HCSF201K)
HC-SF152 - Mitsubishi Melservo HC Servo Motor (HCSF152)
HC-SF152B - Mitsubishi Melservo HC Servo Motor with Brake (HCSF152B)
HC-SF152K - Mitsubishi Melservo HC Servo Motor with Key (HCSF152K)
HC-SF152BK - Mitsubishi Melservo HC Servo Motor with Brake Key (HCSF152BK)
HC-SF202 - Mitsubishi Melservo HC Servo Motor (HCSF202)
HC-SF202BK - Mitsubishi Melservo HC Servo Motor with Brake Key (HCSF202BK)
HC-SF153 - Mitsubishi Melservo HC Servo Motor, 1.5KW (HCSF153)
