CJ1G-CPU43H


Part Number - CJ1G-CPU43H

Product PDF: pdf image

This CJ1G-CPU43H is

In Stock Ships Today!In Stock Ships Today!


\"bulletNew In Stock\"bulletRefurbished In Stock

Call 1-800-479-8084

Rate the CJ1G-CPU43H
5.0/5 on 1 review





Product Details

  • CJ1 Loop Control Module (CJ1GCPU43H)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1G-CPU43H (CJ1GCPU43H) is a control module from the CJ1 series with loop control. The control module has as its external features, a peripheral port and a RS-232C port. The peripheral port is able to connect to various programming consoles or a host computers. The also connects to host computers, but it can also link with programming devices, and programmable terminals. The memory card connector of the CJ1G-CPU43H can attach the chosen memory card to the loop control module. By the connector there is a memory card power supply switch which detaches the power, so that it is safe to remove the card.

The CJ1G-CPU43H loop control module has an Input Output capacity of 960pts for every 30 units it is concatenated with; however it can only have 2 expansion racks. The program capacity has 20K steps. The data memory capacity of the CPU control module has 64K words, 32K words being data memory (DM) and extended memory (EM) 32K words times 1 bank. The current consumption is 1.06 AMP when the voltage is 5V for the CJ1G-CPU43H control module. The current consumption incorporates the current of the programming console. The current can have an extra 0.15 AMP for every adapter if the adapters used are the NT-AL001 RS-232C/RS422A adapters. only 0.04 AMP can be added when using the CJ1W-CIF11 RS-422A adapters.

The CX-Process tool must be used for the CJ1G-CPU43H control module. The CX-process tool should be used with a Microsoft (host computer) as a CD-ROM or DVD-ROM drive. The Microsoft can then connect to either the RS-232C or peripheral interface by an adapter.

Here is the source material referenced:
https://datasheet.octopart.com/CJ1GCPU42H-Omron-datasheet-11549389.pdf
http://www.omonr.com/pdfread/web/viewer.asp?ProductName=OMRON%20CJ1G-CPU44H%20INSTRUCTIONS%20REFERENCE%20MANUAL&brandid=1&Downloadid=10281;
https://assets.omron.eu/downloads/manual/en/v1/w393_cj1m_g_h_cpu_units_operation_manual_en.pdf


Technical Specifications

Part Number: CJ1G-CPU43H (CJ1GCPU43H)
Module Type: Loop Control Module
Number of Input Output Points: 960
Weight: 1lb (approx.)


Related Parts

CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CQM1-OC222 - Omron CQM1 Output Control Module (CQM1OC222)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CJ1G-CPU43H comes with a one-year warranty.
