CJ1W-DRM21
Product PDF:
This CJ1W-DRM21 is
AvailableCall 1-800-479-8084
Product Details
- CJ1 Control Module with DeviceNet (CJ1WDRM21)
- Manufacturer: Omron
- Series: CJ1
Product Description
The Omron CJ1W-DRM21 (CJ1WDRM21) is a CJ1 control module with DeviceNet. This control module can only work in an Omron configuration. This may be connected to a remote Input output terminal if the DRT2 series that acts as a slave in the master/slave relationship. This DRT2 may connect with a myriad of other DRT2-series terminals using the DeviceNet system whose provenance is in the CJ1W-DRM21 control module. All these control module terminals act as smart slaves for a personal computer that behaves as a DeviceNet configuring for the entire system.The CJ1W-DRM21 control module has a communication connector at the base of the module. This connector attached this control module the network by a cable. The power for the communication of this module is contributed by this connection to this connector. Above the connector is a 4-pin DIP switch. Pin 1 and 2 control the baud rate, while pin 3 can resume or cease communications when there is error if the CJ1W-DRM21 module is being employed as a master, finally the 4th pin can hold or clear inputs and outputs for communication errors if the module is used as a slave. Lastly, above that there are three switches: a unit number switch and two node address switch. The unit switch sets the will set the unit number that the CJ1W-DRM21 is within the configuration. The node switches manage the node address.
The CJ1W-DRM21 control module has a power supply voltage whose ambit is between 11 to 25VDC. The current consumption is 18mA for communications and 290mA for the internal circuit.
Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1w-drm21_ds_e_8_6_csm1635.pdf?id=28
Technical Specifications
Part Number: CJ1W-DRM21 (CJ1WDRM21)Module Type: Control Module with DeviceNet
Power Supply: 24VDC
Weight: 0.26lbs (0.118kg)
