Part Number - C200H-CPU01

Product PDF: pdf image

This C200H-CPU01 is


Call 1-800-479-8084

Rate the C200H-CPU01
4.8/5 on 5 reviews

Product Details

  • C200H Output Control Module (C200HCPU01)
  • Manufacturer: Omron
  • Series: C200H

Product Description

The Omron C200H-CPU01 (C200HCPU01) is a C200H control module with output points. The output control module has voltage range from either 100-120VAC or it can range from 200-240VAC. The general frequency is 50/60Hz allowing the voltage to function at a greater rate of either 85-132VAC or 170-264VAC. The C200H-CPU01 control module has a power consumption that is rated to be 120VA. The output of the control module is 3 Amp when operating at 5VDC when it is placed on a CPU rack, and the current and voltage is the same for the expansion rack.

In an Omron configuration, the control module may be placed with a multitude of other modules that are applicable to it. Control modules that can be applied to the configuration are certain input output modules when the CPU rack is being used. On the expansion rack the Input output control module may be used along with a power supply.

All the exterior features of the C200H-CPU01 output control module will be adumbrated below. The control module has a terminal block that may be removed, this terminal block has ten screws. Then there are a total of four connectors, the memory pack and three programming console, one is for the ordinary type, another for the handheld, and the last one is used for storage. The C200H-CPU01 controller has a power fuse that which is positioned next to the terminal block. This control module has five indicators: two of the light up red, the ERROR and OUT INHIBIT; two of them light green, the RUN and POWER; the ALARM will flicker red.

Technical Specifications

Part Number: C200H-CPU01 (C200HCPU01)
Module Type: Control Module
Voltage/Frequency: 100-120VAC or 200-240VAC, 50/60Hz
Weight: 13.27lbs (6.0kg)

Related Parts

C200H-AD002 - Omron C200H Control Module (C200HAD002)
C200H-AD001 - Omron C200H Control Module (C200HAD001)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)
R88D-WT20H - Omron R88D Servo Drive (R88DWT20H)

Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron C200H Shipping options vary by location. Call for an accurate quote.


  • The Omron C200H-CPU01 comes with a one-year warranty.
