Part Number - CJ1H-CPU66H

Product PDF: pdf image

CJ1H-CPU66H is

In Stock Ships Today!In Stock Ships Today!

Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com

Rate the CJ1H-CPU66H
Be the 1st to rate this product listing!

Product Details

  • CJ1 Input Output Control Module (CJ1HCPU66H)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1H-CPU65H (CJ1HCPU65H) is a CJ1 series control module with 2,560 input output points. This input output control module has a current consumption of 0.99 AMP at a voltage of 5V whose LD instruction time is 0.02ms. The CJ1H-CPU65H control module has 2,560 input output points. Its program capacity is 120k steps and its data memory capacity is 256k words. The data memory can be split between the data memory (DM) of 32k words and the extended memory of 32k words times 7 banks (32 x 7).

The Omron configuration of the CJ1H-CPU65H input output control module that needs a memory card attached to the CPU, specifically the HMC-372/672 card. There also must be the CJ1W-PA205R, CJ1W-PA202, or CJ1W-PD025 power supply which is linked to the CPU. Sundry configuration modules, for instance, the basic Input Output, special input output modules and CPU Bus control modules can be fitted into the system with the CJ1W-TER01 end cover placed on either side of the finished configuration. Now the CJ1H-CPU65H can be part of the basic configuration which is simply a power supply and up to ten other control modules, however CPU module can also be deposited on a CPU rack or expansion rack. Either of these racks can be used if more than ten configurations modules are deployed or if the current usage exceeds the capacity that a single power supply can handle. The rack can allow for two power supplies and a divide of the load.

The CJ1H-CPU65H input output control module being a member of the CJ1H family is useful for devices needing speed and a large memory capacity and is very applicable because of its small size, letting it fit in many places.

Here is the source material that may have been referenced:

Technical Specifications

Part Number: CJ1H-CPU65H (CJ1HCPU65H)
Module Type: Control Module
Number of Input Output points: 2,560
Weight: 1lb (approx.)

Related Parts

CJ1M-CPU12 - Omron CJ1 Programmable Control Module (CJ1MCPU12)
CJ1M-CPU13 - Omron CJ1 Control Module (CJ1MCPU13)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)

Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CJ1 Shipping options vary by location. Call for an accurate quote.


  • The Omron CJ1H-CPU66H comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.

Additional Information

TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.

Authorized Distributors

A Omron Authorized Distributor for CJ1 is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron CJ1 parts available for purchase.

More Information: CJ1H-CPU 66 H, CJ1 H CPU 66H, CJ1H CPU 66H, CJ1 H-CPU 66H
