CJ1W-OD211


Part Number - CJ1W-OD211

Product PDF: pdf image

CJ1W-OD211 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CJ1W-OD211
4.0/5 on 3 reviews



Product Details

  • CJ1 Output Control Module (CJ1WOD211)
  • Manufacturer: Omron
  • Series: CJ1

Product Description

The Omron CJ1W-OD211 (CJ1WOD211) is a CJ1 series output control module. The control module has 16 output transistor points and a rated voltage of 12 to 24VDC. The voltage range ambits 10.2 to 26.4VDC and a maximum current load is hinged on the unit and point. There are 0.5 Amp per point and 5.0 Amp per unit. The maximum inrush current has a 4.0 Amp per point with speeds of 10ms at maximum. With the internal current consumption at 100mA when the voltage is at 5VDC. The CJ1W-OD211 output control module also has an external terminal block with terminals named A1-A8 and B0-B8. Screw terminals A0 to A7 and B0 to B7 are all individual output points while A8 is a COM terminal and B8 is a +V terminal with all 16 points participate in one circuit.

When the CJ1W-OD211 is placed in an Omron configuration it is classified as a specialized input output unit and is appropriately placed with the other input and output units. It may be placed next to the CPU suitable for that module. Connections may be made by the CJ1W-OD211 to other modules by the integrated connector on the sides of the module and the slider positioned at the top of the module that secures the connection made.

The 16-point CJ1W-OD211 control module has the dimensions of 31mm by 95.4mm by 89mm (1.22in by 3.76in by 3.5in) measuring width by length by depth if the terminal block is taken into account in the measurement. The weight of the control module is 0.24lbs (0.11kg).

Here is the source material that may have been referenced:
http://www.ia.omron.com/data_pdf/cat/cj1w-oc_oa_od_ds_e_8_7_csm1617.pdf


Technical Specifications

Part Number: CJ1W-OD211 (CJ1WOD211)
Module Type: Output Control Module
Number of Transistor Output Points: 16
Weight: 0.24lbs (0.11kg)
