CQM1-PA206


Part Number - CQM1-PA206

Product PDF: pdf image

CQM1-PA206 is

In Stock Ships Today!In Stock Ships Today!


Contact us to place an order or request a quote:

1-800-479-8084 | sales@trwsupply.com



Rate the CQM1-PA206
4.7/5 on 3 reviews



Product Details

  • CQM1 Control Module with a Built In Power Supply (CQM1PA206)
  • Manufacturer: Omron
  • Series: CQM1

Product Description

The Omron CQM1-PA206 (CQM1PA206) is a CQM1 series control module with a built in power supply. This control module has a built in power supply with a rated voltage span from 100-240VAC and a frequency 50/60Hz. The CQM1-PA206 control module with power supply has a permissible voltage range can go from 85VAC and reaching the voltage range to 265V AC, the output capacity is 30W. The service power supply has a current of 0.5 Amp and an output voltage of 24VDC. The internal current consumption of this power supply is provisory on the CPU unit used. If the unit is the CQM1H-CPU11, the current consumption is 820mA with a voltage of 5VDC. If it is any other CPU of the CQM1H-CPU[][], the current consumption will be 840mA with the standard voltage of 5VDC. The CQM1-PA206 output capacity is 6.0 Amp when the voltage is 5VDC and 0.5 Amp when the voltage is 24VDC.

The CQM1-PA206 control module with a built in power supply can be a constituent of the CQM1H module configuration. The power supply can be connected to the controller link module via the Omron connectors integral to the CQM1-PA206 which are placed on the sides. The control module is connected to the CPU unit. The CPU unit is what then controls the other modules of this configuration, including the CQM1-PA206 control module. The opposing side of the power supply unit may be connected to an end cover to finish the configuration. The end cover is always necessary for the power supply unit due to its placement in the Omron configuration.

Here is the source material that may have been referenced:
https://www.farnell.com/datasheets/1699916.pdf


Technical Specifications

Part Number: CQM1-PA206 (CQM1PA206)
Module Type: Control Module with a Built In Power Supply
Voltage/Frequency: 100-240VAC, 50/60Hz
Weight: 1.2lb (0.54kg)


Related Parts

R88D-WT50H - Omron R88D SERVO DRIVE (R88DWT50H)
CQM1-OC222 - CQM1 Output Control Module (CQM1OC222)
CJ1M-CPU21 - Omron CJ1 Control Module (CJ1MCPU21)



Shipping and Order Information

  • TRW Supply can usually ship in stock items same day before 3:30 PM EST for no extra cost and before 5 PM with a rush fee
  • Omron CQM1 Shipping options vary by location. Call for an accurate quote.

Warranty

  • The Omron CQM1-PA206 comes with a two year warranty.
  • A three year warranty is available. Please inquire for pricing.


Additional Information

TRW Electric & Supply Company is a global automation supplier. We deliver reliable new and refurbished parts at a great value. Our product focus is Omron and Mitsubishi products, but we have been able to provide our customers with solutions from other manufacturers as well. Our goal is to supply the automation industry with the best service and pricing, and of course conduct business with a high level of integrity.






Authorized Distributors

A Omron Authorized Distributor for CQM1 is not the only source for Omron products. Many of the Omron products have been discontinued and therefore are no longer available from authorized suppliers. TRW Electric & Supply has many new and refurbished Omron CQM1 parts available for purchase.


More Information: CQM1-PA 206, CQM1PA206, CQM 1-PA20, CQM 1-PA 206, CQM 1 PA 206



Authorized Distributor small
